Advantech 16 Fast Ethernet +4SFP Managed Ethernet Switch (EKI-7720E-4F-AE)
- 16 Fast Ethernet ports + 4 SFP ports
- SFP socket for Easy and Flexible Fiber Expansion
- Redundancy: X-Ring Pro (ultra high-speed recovery time < 20 ms), RSTP/STP (802.1w/1D)
- IXM function enables fast deployment
- Security: 802.1x (Port-Based, MD5/TLS/TTLS/PEAP Encryption), RADIUS
- Management: SNMP v1/v2c/v3, WEB, Telnet, Standard MIB, Private MIB
- NEMA TS2 for Traffic Control
Deskripsi
| Category | Attribute | Value |
| Power | Power Connector Type | 6-pin removable screw terminal (power & relay) |
| Power Consumption | 12.1W (system) | |
| Power Input (AC) | – | |
| Power Input (Battery) | – | |
| Power Input (DC) | 12 ~ 48 VDC | |
| Power Input (PoE) | – | |
| Power Operating Current | 0.25A @ 48VDC (system) | |
| Redundant Dual Inputs | – | |
| Protection | Overload Current | – |
| Reverse Polarity | Present | |
| Environment | Humidity (Operating Range) | – |
| Relative Humidity | 10~95% | |
| Temperature (Max. Operating) | 60°C (140°F) | |
| Temperature (Min. Operating) | -10°C (14°F) | |
| Temperature (Operating Range) | -10 ~ 60°C (14 ~ 140°F) | |
| Temperature (Storage Range) | -40 ~ 85°C (-40 ~ 185°F) | |
| Mechanism | Dimensions (W x H x D) | 74 x 152 x 105 mm (2.91 x 5.98 x 4.13) |
| Enclosure (Plastic) | – | |
| IP Rating | IP30 | |
| Mounting (DIN-rail) | Yes | |
| Mounting (Panel) | – | |
| Mounting (Pole Mount) | – | |
| Mounting (Rack Mount) | – | |
| Mounting (Stack) | – | |
| Mounting (Wall) | Yes | |
| Weight | 1.1 kg | |
| Ethernet Communication | Ethernet Standard | – |
| Fiber Port Connector Type | SFP cage | |
| Fiber Port Interface | SFP | |
| Fiber Port Number | 4 | |
| Fiber Port Optical Mode | – | |
| Fiber Transmission Distance | Up to 110 km | |
| Fiber Transmission Speed | – | |
| RJ-45 Port Connector Type | 16 x RJ-45 + 4 x SFP ports | |
| RJ-45 Port Number | – | |
| RJ-45 Transmission Distance | 100 m | |
| RJ-45 Transmission Speed | 10/100/1000 Mbps | |
| RJ-45/SFP Combo Port Number | – | |
| RJ-45/SFP Combo Port Speed | – | |
| Switch Properties | Jumbo Frame | 9,216 bytes |
| MAC Table Size | 8K | |
| Packet Buffer Size | 4.1M bit | |
| Switch Fabric Speed | 11.2Gbps | |
| Certification | EMC | EN 61000-4-2 (Level 3), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 3), EN 61000-4-5 (Level 3), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 3) |
| EMI | CE, FCC Class A | |
| EMS | – | |
| Ethernet Standard | IEEE 802.1p, 802.3ad, 802.1x,802.1D, 802.1s, 802.1w | |
| Freefall | IEC 60068-2-32 | |
| Safety | UL 61010-2-201, EN 62368-1 (LVD) | |
| Shock | IEC 60068-2-27 | |
| Vibration | IEC 60068-2-6 | |
| MTBF | Method | Telcordia(Relax), GB |
| Time | – | |
| Warranty | Warranty Period | 5 years |
| PoE Information | PoE Budget | – |
| PoE Output | – | |
| PoE Port Number | – | |
| Support PoE | – |
