Advantech 18-Ch Isolated DI/O Module (ADAM-6050-D)
Rp5.469.803
- 12-ch DI, 6-ch DO, Ethernet-based smart I/O
- Remote monitoring and control with mobile devices
- Group configuration capability for multiple module setup
- Flexible user-defined Modbus address
- Intelligent control ability by Peer-to-Peer and GCL function
- Active I/O message by data stream or event trigger function
- Multiple protocol support: Modbus/TCP, TCP/IP, UDP, HTTP, DHCP, SNMP, MQTT
- Web language support: XML, HTML 5, Java Script
Deskripsi
| Category | Attribute | Value |
| General | Connectors | 1 x RJ45, 1 x 13-pin plug-in screw terminal, 1 x 9-pin plug-in screw terminal |
| Protocol | Modbus/TCP, TCP/IP, UDP, HTTP, DHCP, MQTT, SNMP, ASCII command | |
| Communications | Interface | Ethernet |
| Isolated Digital Input | Channels | 12 |
| Input Voltage | Dry Contact Logic level 0: close to GND Logic level 1: open Wet Contact Logic level 1: 10~30 VDC Logic level 0: 0~3 VDC | |
| Environment | Isolation Voltage | 2,000 VDC |
| Operating Temperature | -40~70 °C (-40~158 °F) | |
| Isolated Digital Output | Channels | 6 |
| Output Type | Sink | |
| Output Voltage | 0~30 VDC | |
| Sink Current | 100 mA max./channel | |
| Power Requirements | Input Voltage | 10~30 VDC |
