Advantech CIRCUIT MODULE, Magnet Strip Reader, Black, for UTC-300 Series (UTC-300P-M21E)
Deskripsi
| Category | Attribute | Value |
| Best Fit | Best Fit | for UTC-318/320 |
| Dimensions | Dimensions | 101 x 37 x 25 mm |
| Operating Temperature | External Power | 0 ~ 40° C |
| Interface | Interface | USB |
| Track Configuration | Track Configuration | TRACK 1 / IATA / 210 bpi / 79 Alphanumeric,TRACK 2 / ABA / 75 bpi / 40 Numeric Characters,TRACK 3 / Thrift / 210 bpi / 107 Numeric Characters |
| Card Standard | Card Standard | ANSI/ISO Standards 7810,7811-1~6, 7813 |
| Read Speed | Read Speed | 3 ips to 60 ips (7 cm/s to 152 cm/s) |
| Magnetic Head Life | Magnetic Head Life | 1,000,000 times (ISO test standard) |
Informasi Tambahan
| Brand |
Advantech |
|---|
