Advantech COMPUTER SYSTEM, DS-370, J1900 w/o uSSD, barebone (DS-370GB-U0A1E)
Deskripsi
SPESIFICATION
| Category | Attribute | Value |
| Display | Graphic Engine | DirectX 11.1, OGL 3.0, OCL 1.1, OGL ES 2.0;Encode: H.264, MPEG2/4, VC1, WMV9;Decode: H.264, MPEG2 |
| Display | Max. Resolution | VGA: 2048 x 1280 @ 60Hz;HDMI: 1920 x 1080 @ 60Hz;DP++: 1920 x 1080 @ 60Hz |
| Display | Output | Dual Display |
| Display | Processor Graphics | Intel® HD Graphics |
| I/O | Audio | 1 x Mic-in, 1 x SPDIF/Line-Out(support jack-sense via OS setting) |
| I/O | DP++ | 1 |
| I/O | HDMI | 1 |
| I/O | LAN | 2 |
| I/O | Mini-PCIe (Internal) | 2 x Full-size Mini PCIe |
| I/O | Power input | 1 (DC-in Jack) |
| I/O | Serial port | 2 x RS-232 |
| I/O | SIM Socke | 1 x SIM card size (Optional) |
| I/O | USB2.0 | 3 |
| I/O | USB3.0 | 1 |
| I/O | VGA | 1 |
| Memory | Max. Capacity | 8GB (up to 4GB per SO-DIMM) |
| Memory | Socket | 2 x 204-pin SO-DIMM |
| Memory | Technology | DDR3L 1333 MHz |
| Processor | BIOS | AMI uEFI 64Mbit |
| Processor | CPU | Intel® Celeron™ Processor J1900 Quad Core 2.0 GHz SoC |
| Storage | Others | mSATA via MiniPCIe slot |
| Storage | SATA | 1 x 2.5-inch SATA II HDD/SSD (only support 7 mm height) |
| Environment | Operating Temperature | 0 ~ 40° C (32 ~ 104° F) (w / HDD) |
| Ethernet | Controller | 2 x Intel I211 |
| Ethernet | Interface | Gigabit LAN Controller |
| Environment | Relative Humidity | 95% @ 40° C (non-condensing) |
| Watchdog Timer | Interval | Programmable by SUSIAccess |
| Watchdog Timer | Output | Interrupt, system reset |
| Power Requirement | Input Voltage | 19V DC-in (ATX/AT mode, default ATX) |
| Power Requirement | Management | ACPI 3.0 |
| Power Requirement | Others | Supports Boot on Power back and schedule boot up function |
| Power Requirement | Power Consumption Input Voltage | Idle Mode: 4.39W (w/o expansion) Full Mode:10.85W (w/o expansion) |
| Certification | EMC | FCC class B/CCC/BSMI |
| Certification | Safety Certifications | UL, CB, CCC, BSMI |
| Software Support | Linux | Linux Fedora 20 |
| Software Support | Microsoft Windows | WES7E, Windows 7, WE8S, Windows 8 |
| Physical Characteristics | Dimensions(W x D x H) | 204x 118.2 x 44.2 mm |
| Physical Characteristics | Mounting | Supports VESA/DIN Rail/Wall Mounting (Optional) |
| Physical Characteristics | Weight | 1.1 kg |
Informasi Tambahan
| Brand |
Advantech |
|---|
