Advantech COMPUTER SYSTEM, UBC-330 TI AM3352 1GHz, 512MB DDR3 (UBC-330NS-JLA1E)
Deskripsi
| Category | Attribute | Value |
| Display | Graphic Engine | N/A |
| Display | H/W Video Codec | N/A |
| Display | HDMI | N/A |
| Display | VGA | N/A |
| I/O | Audio | N/A |
| I/O | Reset Button | 1 |
| I/O | SDIO | 1 SD card slot |
| I/O | Serial port | 6 x RS232 |
| I/O | SPDIF | N/A |
| I/O | USB | 1 USB Host / OTG |
| Memory | Capacity | On-board DDR3 512 MB |
| Memory | Flash | 4 GB eMMC for O.S. and 4 MB NOR Flash for Advantech boot loader |
| Memory | Technology | DDR3 800 MHz |
| Processor | CPU | TI Sitara Cortex A8 AM3352 1Ghz |
| Operating System | Linux | Linux Kernel V3.2.0 |
| Operating System | Others | Linux |
| Environment | Humidity | 5%~95% Relative Humidity, non-condensing |
| Environment | Operational Temperature | 0 ~ 55° C |
| Power | Power Consumption (Full Load) | TBC |
| Power | Power Supply Voltage | 12 / 19 / 24V DC-In |
| Power | Power Type | AT DC-In |
| Ethernet | Chipset | TI AM3352 Integrated RGMII |
| Ethernet | Speed | 2 x 10/100/1000Mbps |
| Watchdog Timer | WatchDog Timer | MSP430G2202 (time out:1~6553s,default 60s/power on/off 1s) |
| Certification | EMC | CE / FCC / CCC / Class B |
| Expansion | SD Socket | 1 SD card slot |
| Physical | Dimension (mm) | 117 x 166 x 30mm |
| Physical | Mounting | Wall mount, VESA 75/100, Flexible mount with two screw holes on the metal plate |
| Physical | Weight | 265g |
| RTC | RTC | Yes |
| Indicator | LED | 1 Green LED for the system power |
Informasi Tambahan
| Brand |
Advantech |
|---|
