Advantech ULI-232TC – 3-Way Isolated RS-232 (DB9 Male / Female) DIN Rail Repeater (BB-232OPDR)
- Extend RS-232 Data another 50 ft (15.2 m)
- 2000V Optically Isolated Data Lines
- -40 to 80°C Operating Temperature
- Complies with NEMA TS1 & TS2 Environmental requirements for Traffic Control Equipment
Deskripsi
| Category | Attribute | Value |
| General | Isolation | 2kV |
| General | Mounting | DIN |
| General | Power | 10-30VDC |
| General | Serial Type | RS-232 |
| General | Technology | Serial |
| General | Temperature | -40 to 80C |
| Power | Power Input (DC) | 10 ~ 30 VDC |
| Protection | ESD Protection | 8 kV (Air) |
| Protection | Isolation | 2,000 VDC |
| Serial Communication | Maximum Serial Transmission Speed | 115.2 Kbps |
| Serial Communication | Repeater Maximum Distance | 15 Meters |
| Serial Communication | Serial Port Connector Type | Terminal block |
| Serial Communication | Serial Port Number | 1 |
| Serial Communication | Serial Standard | RS-232 |
| Environment | Temperature (Operating Range) | -40 ~ 80°C (-40 ~ 176°F) |
| Accessory General | Mounting | Panel, DIN |
Informasi Tambahan
| Brand |
Advantech |
|---|
