APC Easy UPS On-Line, 3kVA/2700W, Rackmount 2U, 230V (SRV3KRIRK-E)
Rp17.250.001
Deskripsi
Spesifikasi
| Presentation | High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions. |
|---|---|
| Lead time | Usually in Stock |
|
Kapasitas Maks. Digunakan
information_stroke
|
100 % |
|---|---|
| Main Input Voltage | 230 V |
| Other Input Voltage | 220 V 240 V |
| Main Output Voltage | 230 V |
| Other Output Voltage | 220 V 240 V |
| Rated power in W | 2700 W |
| Rated power in VA | 3000 VA |
| Input Connection Type | IEC 60320 C20 |
| output connection type | 6 IEC 60320 C13 1 IEC 60320 C19 |
| Number of rack unit | 2U |
| Cable length | 1.5 m |
| Number of cables | 1 |
| Provided equipment | 1 IEC 60320 C19 to Schuko power cable 1 IEC 60320 C13 to C14 power cable 1 USB cable 1 RS-232 configuration cable 1 rack mounting brackets 1 rack mounting support rails user manual |
| Run-time | View Runtime Graph
action_new_window
|
|---|---|
| Efisiensi | View Efficiency Graph
action_new_window
|
| battery type | Lead-acid battery |
| battery voltage | 72 V |
| Number of battery filled slots | 0 |
| Number of battery free slots | 0 |
| Battery recharge time | 4 h |
| Battery life | 3…5 year(s) |
| Replacement battery | APCRBCV202
action_new_window
|
| Battery charger power | 60 W rated |
| Max runtime | 3 min |
|---|---|
| Number of power module filled slots | 0 |
| Number of power module free slots | 0 |
| Redundant | No |
| Input voltage limits | 110…285 V half load 180…285 V full load |
|---|---|
| Network frequency | 40…70 Hz auto sensing |
| Maximum configurable power in VA | 3000 VA |
|---|---|
| Maximum configurable power in W | 2700 W |
| Output frequency | 50/60 Hz +/- 3 Hz sync to mains |
| Harmonic distortion | 3 % |
| UPS type | Double conversion online |
| Wave type | Sine wave |
| Efficiency | 88 % (full load) |
| additional information | Configurable for 220 : 230 or 240 nominal output voltage |
| bypass type | Internal bypass (automatic and manual) |
| Crest factor | 3 : 1 |
