| Output | |
| Max Configurable Power (Watts) | 1.6kWatts / 2.0kVA |
| Output Voltage Note | Configurable for 220 : 230 or 240 nominal output voltage |
| Efficiency at Full Load | 88.0 % |
| Output Frequency (sync to mains) | 50/60 Hz +/- 3 Hz Sync to mains |
| Other Output Voltages | 220, 240 |
| Load Crest Factor | 3 : 1 |
| Topology | Double conversion online |
| Waveform type | Sine wave |
| Bypass | Internal bypass (automatic and manual) |
| Input | |
| Input frequency | 40 – 70 Hz |
| Input voltage range for main operations | 110 – 285 Adjustable (half load), 160 – 280V |
| Number of Power Cords | 1 |
| Efficiency at Full Load | 88.0 % |
| Other Input Voltages | 220, 240 |
| Batteries & Runtime | |
| Battery type | Lead-acid battery |
| Typical recharge time | 4hour(s) |
| Battery Charge Power (Watts) | 76 Watts |
| Communications & Management | |
| Interface Port(s) | DB-9 RS-232, USB |
| Control panel | Multifunction LCD status and control console |
| Audible Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Available SmartSlot™ Interface Quantity | 1 |
| Surge Protection and Filtering | |
| Surge energy rating | 600Joules |
| Physical | |
| Maximum Height | 86MM, 8.6CM |
| Maximum Width | 437MM, 43.7CM |
| Maximum Depth | 462MM, 46.2CM |
| Net Weight | 18.2KG |
| Conformance | |
| Approvals | CE, EAC, IEC 62040-1-1, IEC 62040-1-2 |
| Standard warranty | 2 years repair or replace |
