Spesifikasi singkat:
Output | |
Max Configurable Power (Watts) | 2.7kWatts / 3.0kVA |
Output Voltage Note | Configurable for 220 : 230 or 240 nominal output voltage |
Output Frequency (sync to mains) | 50/60 Hz +/- 3 Hz Sync to mains |
Other Output Voltages | 220, 240 |
Topology | Line interactive |
Waveform type | Sine wave |
Transfer Time | 4 ms typical |
Input | |
Input frequency | 50/60 Hz +/- 3 Hz Auto-sensing |
Input voltage range for main operations | 151 – 302 Adjustable, 160 – 286V |
Number of Power Cords | 1 |
Other Input Voltages | 220, 240 |
Batteries & Runtime | |
Battery type | Lead-acid battery |
Typical recharge time | 3hour(s) |
Replacement Battery | RBC43 |
Expected Battery Life (years) | 3 – 5 |
RBC Quantity | 1 |
Battery Charge Power (Watts) | 182 Watts |
Extendable Run Time | 1 |
Communications & Management | |
Interface Port(s) | RJ-45 10/100 Base-T, RJ-45 Serial, SmartSlot, USB |
Pre-Installed SmartSlot™ Cards | AP9631 |
Control panel | LED status display with on line : on battery : replace battery and overload indicators, Multifunction LCD status and control console |
Audible Alarm | Alarm when on battery : distinctive low battery alarm : configurable delays |
Emergency Power Off (EPO) | Optional |
Surge Protection and Filtering | |
Surge energy rating | 320Joules |
Physical | |
Maximum Height | 86MM, 8.6CM |
Maximum Width | 480MM, 48.0CM |
Maximum Depth | 683MM, 68.3CM |
Net Weight | 44.19KG |
Conformance | |
Approvals | CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE |
Standard warranty | 3 years repair or replace (excluding battery) and 2 years for battery |
