Output | |
Max Configurable Power (Watts) | 2.1kWatts / 3.0kVA |
Output Voltage Distortion | Less than 5 % at full load |
Output Frequency (sync to mains) | 50 Hz Sync to mains |
Topology | Line interactive |
Waveform type | Sine wave |
Input | |
Input frequency | 47 – 63 Hz |
Input voltage range for main operations | 170 – 300 Adjustable, 180 – 287V |
Other Input Voltages | 220, 240 |
Batteries & Runtime | |
Battery type | Lead-acid battery |
Typical recharge time | 3hour(s) |
Replacement Battery | APCRBC150 |
RBC Quantity | 1 |
Battery Charge Power (Watts) | 183 Watts |
Communications & Management | |
Interface Port(s) | USB |
Control panel | Multifunction LCD status and control console |
Audible Alarm | Alarm when on battery : distinctive low battery alarm : configurable delays |
Surge Protection and Filtering | |
Surge energy rating | 300Joules |
Filtering | Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
Physical | |
Maximum Height | 435MM, 43.5CM |
Maximum Width | 197MM, 19.7CM |
Maximum Depth | 544MM, 54.4CM |
Net Weight | 43.0KG |
Conformance | |
Approvals | C-Tick, CE, EAC, GOST, SABS, VDE |
Standard warranty | 2 years repair or replace |
