Cisco Aggregation Series Router ASR1006-10G-B16/K9
Rp2.710.620.000
Deskripsi
SPESIFICATION
| Device Type | Router – with 2 x Cisco ASR 1000 Series Embedded Services Processor, 10Gbps / 2 x Route Processor 1 / SPA Interface Processor 10G |
| Enclosure Type | Desktop, rack-mountable – modular – 6U |
| Connectivity Technology | Wired |
| Performance | Bandwidth: 10 Gbps |
| Capacity | Concurrent L2TP VPN tunnels: 12000 ¦ Concurrent sessions: 24000 ¦ IPSec VPN tunnels: 10000 ¦ NAT entries: 500000 ¦ ACL rules: 4000 ¦ QoS hardware entries: 128000 |
| Remote Management Protocol | SNMP, Telnet, SSH |
| Features | VPN support, MPLS support, IPv6 support, Stateful switchover (SSO), MPLS VPN |
| Compliant Standards | CISPR 24, EN55022, VCCI Class A ITE, EN55024, CISPR 22, EN50082-1, CSA 22.2 No. 60950, EN 61000-6-1, AS/NZS 60950-1, AS/NZ 3548 Class A, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1 |
| RAM | 8 GB |
Expansion / Connectivity
| Interfaces | Management: 2 x 10Base-T/100Base-TX – RJ-45 ¦ Management: 2 x console – RJ-45 ¦ Management: 2 x auxiliary – RJ-45 ¦ USB: 1 x |
| Expansion Slots | 2 (total) / 0 (free) x processor board ¦ 17 (total) / 14 (free) x expansion slot |
| Installed Modules Qty (Max) | 5 (installed) / 19 (max) |
Power
| Power Device | Internal power supply |
| Power Redundancy | Yes |
| Installed Qty | 2 (installed) / 2 (max) |
Miscellaneous
| Rack Mounting Kit | Included |
Software / System Requirements
| OS Provided | Cisco IOS Advanced IP services |
Dimensions & Weight
| Width | 17.2 in |
| Depth | 21.9 in |
| Height | 10.5 in |
Environmental Parameters
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 – 90% |
