Cisco Integrated Service Router C2801-VSEC-CUBE/K9
Rp62.537.400
- 2801 VSEC Bundle w/PVDM2-8,FL-CUBE,AVS,128F/384D
Deskripsi
| Communications | |
|---|---|
| Digital Ports Qty: | 8 |
| Type: | Voice / fax module |
| Dimensions & Weight | |
|---|---|
| Depth: | 41.9 cm |
| Height: | 4.4 cm |
| Weight: | 6.2 kg |
| Width: | 44.5 cm |
| Environmental Parameters | |
|---|---|
| Humidity Range Operating: | 10 – 85% |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Expansion / Connectivity | |
|---|---|
| Expansion Slots: | 2 (total) / 2 (free) x AIM ¦ 2 (total) / 2 (free) x HWIC ¦ 1 (total) / 1 (free) x WIC ¦ 1 (total) / 1 (free) x VIC ¦ 2 (total) / 1 (free) x PVDM ¦ CompactFlash ¦ Memory |
| Interfaces: | USB: 1 x ¦ Serial: 1 x auxiliary – RJ-45 ¦ Management: 1 x console – RJ-45 ¦ 2 x 10Base-T/100Base-TX – RJ-45 ¦ WAN: 1 x ADSL |
| General | |
|---|---|
| Compliant Standards: | CISPR 22 Class A, CISPR 24, EN 61000-3-2, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, EN55022 Class A, UL 60950, EN50082-1, CSA 22.2 No. 60950, AS/NZ 3548 Class A, JATE, FCC Part 15, ICES-003 Class A, CS-03, EN 61000-6-2 |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Ethernet, Fast Ethernet |
| Device Type: | Router |
| Enclosure Type: | Desktop – modular – 1U |
| Features: | Firewall protection, MPLS support, VLAN support, URL filtering |
| Flash Memory: | 64 MB (installed) / 128 MB (max) |
| Network / Transport Protocol: | IPSec |
| RAM: | 256 MB (installed) / 384 MB (max) |
| Remote Management Protocol: | SNMP 3 |
| IP Telephony | |
|---|---|
| IP Telephony Features: | Echo cancellation (G.168) |
| Voice Codecs: | G.711, G.723.1, G.728, G.729, G.729a, G.729ab, G.726 |
| Line Properties | |
|---|---|
| Framing Format: | G.711, G.723.1 |
| Power | |
|---|---|
| Power Device: | Internal power supply |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
