Deskripsi

Camera

Image Sensor 1/2.8″ STARVIS™ CMOS
Pixel 4MP
Max. Resolution 2560 (H) × 1440 (V)
ROM 4GB
RAM 1GB
Electronic Shutter Speed 1/1 s–1/30,000 s
Scanning System Progressive
Min. Illumination Color: 0.005Lux@F1.8
B/W: 0.0005Lux@F1.8
0Lux (IR light on)
Illumination Distance 15 m (49.21 ft)
Illuminator On/Off Control Zoom Prio/Manual/SmartIR
Illuminator Number 3

Lens

Focal Length 2.8 mm–12 mm
Max. Aperture F1.8–F2.7
Field of View H: 31.6°–96.9°
V: 17.8°–51.4°
D: 36.4°–116.2°
Optical Zoom 4x
Focus Control Auto/Semi-Auto/Manual
Close Focus Distance 0.2 m–0.5 m (0.66 ft–1.64 ft)
Iris Control Auto
DORI Distance Detect Observe Recognize Identify
147.0 m (482.28 ft) 58.8 m (192.91 ft) 29.4 m (96.46 ft) 14.7 m (48.23 ft)

PTZ

Pan/Tilt Range Pan: 0°–355°
Tilt: 5°–90°
Manual Control Speed Pan: 0.1°/s–70°/s
Tilt: 0.1°/s–30°/s
Preset Speed Pan: 80°/s
Tilt: 40°/s
Presets 300
Tour 8 (up to 32 presets per tour)
Speed Adjustment Support
Power-off Memory Support
Idle Motion Preset/Tour

General Intelligence

Event Trigger Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal Access, Storage anomaly
IVS Object Abandoned/Missing

Artificial Intelligence

People Counting Count people entering and exiting the area (crossing people counting); count people staying in the area (in-area people counting); display and export reports by day, week and month.
Perimeter Protection Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc.
SMD Plus Support
Face Detection Support

Video

Compression H.265; H.264BaselineProfile; H.264MainProfile; H.264HighProfile; MJPEG (Sub Stream); H.265+; H.264+
Streaming Capability 3 streams
Resolution 4M (2560 x 1440); 3M (2048 x 1536); 1080P (1920 x 1080); 1.3M (1280 x 960); 720P (1280 x 720); D1 (704 x 576/704 × 480); CIF (352 x 288/352 × 240)
Frame Rate Main stream: 4M/3M (1–25/30fps), 1080P/1.3M/720P (1–25/30fps)
Sub stream 1: D1/CIF (1–25/30fps)
Sub stream 2: 720P (1–25/30fps), D1/CIF (1–25/30fps)
Bit Rate Control Variable Bit Rate/Constant Bit Rate
Bit Rate H.264/H.265/MJPEG: 3 kbps–20480 kbps
Day/Night Auto (ICR)/Color/B/W
BLC Support
WDR 120 dB
HLC Support
White Balance Auto/Indoor/Outdoor/Track/Manual/Sodium lamp/Natural light/Street lamp
Gain Control Auto/Manual
Noise Reduction 2D/3D
Motion Detection Support
Region of Interest (RoI) Support
Electronic Image Stabilization Support
Electronic Defog Support
Digital Zoom 16x
Flip 0°/180°
Privacy Masking Up to 24 areas, and up to 8 areas in the same view

Audio

Compression G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G.722.1; G.729; G.723

Network

Ethernet RJ-45 (10/100Base-T)
Protocol IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMPv1/v2c/v3(MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP
Interoperability ONVIF Profile S&G&T; CGI
Streaming Method Unicast/Multicast
User/Host 20
Storage FTP; Micro SD card (256G); P2P
Browser IE; Chrome; Firefox; Safari (no version restriction)
Management Software SmartPSS
DSS
Mobile Phone iOS/Android

Certification

Certifications CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014UL62368-1+CAN/CSA C22.2,No. 62368-1

Port

Audio Input 1(Line in; bare wire or built in Mic)
Audio Output 1

Power

Power Supply DC12V/1.5A±15%
PoE (802.3af)
Power Consumption 3W
8.5W (IR on)
