Dell networking S4112F-ON
Rp169.129.868
Deskripsi
Specifications:
| S4112F-ON | S4112T-ON | S4128F-ON | S4128T-ON | S4148F-ON | S4148FE | S4148T-ON | S4148U | |
|---|---|---|---|---|---|---|---|---|
| Ports | 12xSFP+ 3xQSFP28 |
12x10GbT 3xQSFP28 |
28xSFP+ 2xQSFP28 |
28x10GbT 2x QSFP28 |
48xSFP+ 2xQSFP+ 4xQSFP28 |
48xSFP+ 2xQSFP+ 4xQSFP28 |
48x10GbT 2xQSFP+ 4xQSFP28 |
48xSFP+ 2xQSFP+ 4xQSFP28 |
| Unified port | N/A | N/A | N/A | N/A | N/A | N/A | N/A | Support |
| Max 10GbE density | 24 (12 SFP+ and 12 via QSFP28 breakout) | 24 (12 10GbT and 12 via QSFP28 breakout) | 36 (28 SFP+ and 8 via QSFP28 breakout) | 36 (28 10GbT and 8 via QSFP28 breakout) | 72 (48 SFP+ and 24 via QSFP28 breakout) | 72 (48 SFP+ and 24 via QSFP28 breakout) | 72 (48 10GbT and 24 via QSFP28 breakout) | 72 (48 SFP+ and 24 via QSFP28 breakout) |
| Max 25GbE density | 12 via QSFP28 breakout | 12 via QSFP28 breakout | 8 via QSFP28 breakout | 8 via QSFP28 breakout | 16 via QSFP28 breakout | 16 via QSFP28 breakout | 16 via QSFP28 breakout | 16 via QSFP28 breakout |
| Max 40GbE density | 3 | 3 | 2 | 2 | 6 | 6 | 6 | 6 |
| Max 50GbE density | 6 | 6 | 4 | 4 | 8 | 8 | 8 | 8 |
| Max 100GbE density | 3 | 3 | 2 | 2 | 4 | 4 | 4 | 4 |
| Max FC 8G/16G ports (oversubscribed) | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 40 |
| Max FC 16G line rate | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 28 |
| Max FC 32G ports (oversubscribed) | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 16 |
| Max FC 32G line rate | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 8 |
| Switching capacity | 840Gbps | 840Gbps | 960Gbps | 960Gbps | 1.76Tbps | 1.76Tbps | 1.76Tbps | 1.76Tbps |
| Throughput | 630Mpps | 630Mpps | 720Mpps | 720Mpps | 1320Mpps | 1320Mpps | 1320Mpps | 1320Mpps |
| LRM optics support | No | No | No | No | No | Yes | No | No |
| 1588v2 PTP timing | No | No | No | No | Yes | Yes | Yes | Yes |
| Max power consumption | 180W | 200W | 260W | 300W | 370W | 400W | 440W | 460W |
| Typical operating power | 90W | 120W | 160W | 250W | 200W | 240W | 320W | 300W |
| Number of fan trays | Fixed | Fixed | 4 | 4 | 4 | 4 | 4 | 4 |
| Fans per fan tray | 3 | 3 | 1 | 1 | 1 | 1 | 2 | 2 |
| Weight | 8.30lbs | 8.45lbs | 19.66 lbs (8.92 kg) |
20.67 lbs (9.38 kg) |
20.15 lbs (9.14 kg) |
20.85 lbs (9.46 kg) |
22.37 lbs (10.15 kg) |
20.52 lbs (9.31 kg) |
| Max thermal output | 614 BTU/h | 682 BTU/h | 886 BTU/h | 1,023 BTU/h | 1261 BTU/h | 1,364 BTU/h | 1,500 BTU/h | 1,568 BTU/h |
Include
- 1x VLT Tech Sheet Document
- 1x Info Mod – Factory Pass Through Process
- 1x Boxing Label Mod
- 1x Dell Networking Dual Tray, one Rack Unit, 4-post rack only, S4112
- 2x Jumper Cord – C13/C14, 2M, 250V, 10A (EU, TW, APCC countries except ANZ)
- 1x Dell EMC Networking S4112-ON APJC User Guide
- 1x OS10 Enterprise, S4112T
- Partner Operations Support B2B
- 3 Years ProSupport OS10 Enterprise Software Support-Maintenance
- Limited Warranty:Yr1 Return to Depot (Parts)
- 3Yr ProSupport:Next Business Day Onsite Service
- 3Yr ProSupport:(7×24) Technical Support & Assistance
- Yr1 ProSupport:Next Business Day Onsite Service
- Yr2-3 ProSupport:Next Business Day Onsite Service
- Visit //www.dell.com/contactdell
- No Installation Service Required
- Technical Support
