Edge Core 16x10G SFP+ and 2x40G QSFP+ uplinks (ECS5520-18X)
Rp63.688.748
- High-performance 10G Layer 2+ /Lite L3 managed switch with 480 Gbps switching capacity
- Ideal solution for traditional three-tier aggregation or core topologies and folded-Clos architectures, serving with a 2:1 oversubscription
- 16 x 10G SFP+ + 2 x 40G QSFP+ uplinks
- Full L2+ feature with static route
- Dual hot swappable, load sharing power supplies to ensure the reliability of the switch
- Optional 2nd AC power module for redundancy & DC power module
Deskripsi
Port |
10G SFP+ Ports | 16 |
| 10GBASE-T Ports | 0 | |
| 40G QSFP+ Ports | 2 | |
| GE out-of-band Management Port | 1 | |
| RJ-45 Console Port | 1 | |
| USB Port | 1 | |
Performance |
Switching Capacity | 480 Gbps |
| Forwarding Rate | 357.12 Mpps | |
| Flash Memory | 1GB NAND, 32MB SPI NOR | |
| DRAM | 2 GB | |
| MAC Address Table | 64K (shared with L2, multicast, L3 table) | |
| Jumbo Frames | 10 K | |
| Auto-negotiation, Auto-MDI/MDIX (Copper port) | Auto-MDI/MDIX (Copper port) only | |
Power Supply |
AC Power Supply Module (100-240 VAC, 50/60 Hz) |
1 (Optional 2nd Power module for redundancy) |
| DC Power Module (-36- -72VDC) |
Yes (Optional) | |
| Max System Power Consumption (Watts) | 132 W | |
| Dying Gasp | No |
