Edge Core 8 ports 10/100/1000Base-T + 2G SFP uplink ports with 8 port PoE (ECS2020-10P)
Rp46.809.394
- Support 2/4 integrated Gigabit SFP ports. Besides providing more uplink bandwidth, the SFP ports can be used for redundant links.
- Operate at a temperature from 0-50ºC.
- Supports automatic voice/surveillance VLANs, providing VoIP and IP cameras the optimum network traffic usage.
- 4KV Surge Protection
- IGMP/MLD snooping manages multicast streams to ensure high-quality, smooth video.
- Supports Web, SNMP v1/v2c/v3, and Telnet management to provide CLI access. The switch supports a private MIB for detailed information.
Deskripsi
Port |
RJ-45 10/100/1000 Ports | 8 |
| 100/1000 SFP Ports | 2 (1G) | |
| PoE Ports | 8 | |
| Console Port | No | |
Performance |
Switching Capacity | 20 Gbps |
| Forwarding Rate | 14.9 Mpps | |
| Flash Memory | 16 MB | |
| DRAM | 128 MB | |
| MTBF | 118,824 hrs | |
| Packet Buffer | 4.1 Mbits | |
| MAC Address Table | 8 K | |
| Jumbo Frames | 10 K | |
| Heat Dissipation | 272.96 (Btu/H) | |
| Acoustic Noise | 0 dB (A) | |
Power Supply |
100-240 VAC, 50-60 Hz | Yes |
| Max System Power Consumption (Watts) | 80 W | |
PoE |
IEEE 802.3af/802.3at | Yes |
| PoE Power Budget | 70 W | |
| PoE Timer | Yes |
ECS2020 Series DatasheetKarena padatnya alur keluar-masuk barang, para pembeli wajib :
