| Camera | |
| Image Sensor | 1/2.7″ Progressive Scan CMOS |
| Min. Illumination | Color: 0.028 Lux @ (F2.0, AGC ON) |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Slow Shutter | Yes |
| Angle Adjustment | Pan: 0° to 360°, tilt: -90° to 90°, rotate: 0° to 90° |
| WDR | DWDR |
| Day & Night | IR Cut Filter |
| Lens | |
| Aperture | F2.0 |
| Focus | Fixed |
| FOV | · 2.8 mm, horizontal FOV: 114.5°, vertical FOV: 62°, diagonal FOV: 135.5°
· 4 mm, horizontal FOV: 86°, vertical FOV: 46.5°, diagonal FOV: 102.5° |
| Lens Mount | M12 |
| Focal length | 2.8/4 mm |
| Network | |
| Network Storage | Support micro SD/SDHC/SDXC card (max. 256 GB), local storage and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Protocols | TCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, RTP, RTSP, NTP, UPnP, IGMP, IPv6, UDP, QoS, Bonjour |
| User/Host | · Up to 32 users
· 3 levels: Administrator, Operator and User |
| Client | · Wired network: Hik-Connect, iVMS-4200
· Wi-Fi: iVMS-4200 · *Wi-Fi connection with Hik-Connect directly is not possible. |
| Audio | |
| Environment Noise Filtering | Yes |
| Audio Sampling Rate | 8 kHz/16 kHz |
| Image | |
| Max. Resolution | 1920 × 1080 |
| Main Stream | · 50Hz: 25 fps (1920 × 1080, 1280 × 720)
· 60Hz: 30 fps (1920 × 1080, 1280 × 720) |
| Sub-Stream | · 50Hz: 25 fps (640 × 360)
· 60Hz: 30 fps (640 × 360) |
| Image Enhancement | BLC, HLC, 3D DNR |
| Day/Night Switch | Day, night, auto, scheduled |
| Image Settings | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Wi-Fi (-W) | |
| Wireless Standards | IEEE 802.11b/g/n |
| Frequency Range | 2.4 GHz to 2.4835 GHz |
| Transfer Rates | · 11b: 11 Mbps
· 11g: 54 Mbps · 11n: up to 150 Mbps |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Channel Bandwidth | 20 MHz/40 MHz |
| Wireless Range | Up to 80 m (The performance varies based on actual environment.) |
| Protocols | · 802.11b: CCK, DQPSK, DBPSK
· 802.11g/n: 64-QAM, 16-QAM, QPSK, BPSK |
