HikVision 4 Port Fast Ethernet Smart POE Switch (DS-3E1106P-EI)
Rp742.154
- × 10/100 Mbps PoE port,2 × 10/100 Mbps RJ45 port
- Total PoE Power Budget 60W
- Support 802.1Q VLAN
- Support PoE watchdog to detect and restart the cameras that do not respond
- Support STP/RSTP Loop prevention
Deskripsi
Spesifikasi :
| Shell | Metal material |
| Net Weight | 0.27 kg (0.6 lb) |
| Gross Weight | 0.77 kg (1.7 lb) |
| Dimensions | 121.1 mm × 27.6 mm × 83.1 mm (4.77” × 1.09” × 3.27”) |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Storage Temperature | -40 °C to 85 °C (-40 °F to 185 °F) |
| Operating Humidity | 5% to 95% (no condensation) |
| Relative Humidity | 5% to 95% (no condensation) |
| Power Supply | 100-240 VAC, 50/60 Hz, Max. 4 A |
| Installation Mode | Desk-Mounted,Wall-Mounted |
| Max. Power Consumption | 65 W |
| Power Consumption in Idle | 1.6 W |
| Surge Protection | 6 KV |
| Port | 4 × 10/100 Mbps PoE port,2 × 10/100 Mbps RJ45 port |
| MAC Address Table | 2 K |
| Switching Capacity |
14 Gbps |
| Packet Forwarding Rate |
10.42 Mpps |
| Internal Cache | 1 Mbits |
| PoE Power Supply | |
| PoE Standard | IEEE 802.3af,IEEE 802.3at |
| PoE Power Pin | End-span: 1/2(-), 3/6(+) |
| PoE Port | PoE: Ports 1 to 4 |
| Max. Port Power | 30 W |
| PoE Power Budget | 60 W |
