| Camera | |
| Image Sensor | 1/2.9″ Progressive Scan CMOS |
| Min. Illumination | Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Slow Shutter | Yes |
| Wide Dynamic Range | 120 dB |
| Day & Night | ICR Cut |
| Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 355° |
| Lens | |
| Lens | 2.8 to 12 mm;Motorized |
| Auto-Iris | No |
| Aperture | F1.6 |
| Focus | Auto |
| FOV | Horizontal field of view: 88° to 27°,Vertical field of view: 56° to 18°,Diagonal field of view: 110° to 33° |
| Lens Mount | Φ14 |
| Network | |
| User/Host | Up to 32 users,3 levels: Administrator, Operator and User |
| Client | iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500 |
| Network Storage | Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Video | |
| Max. Resolution | 3072 × 2048 |
| Main Stream | · 50Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
· 60Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 30fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub Stream | · 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
· 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Third Stream | · 50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)
· 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
| Video Compression | · Main stream: H.265/H.264
· Sub-stream: H.265/H.264/MJPEG · Third stream: H.265/H.264 |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Main Profile/High Profile |
| H.265 Type | Main Profile |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding support |
| Image | |
| Day/Night Switch | Day/Night/Auto/Schedule/Triggered by Alarm In |
