Kabel SUPREME NYY 4×70 /meter
Rp778.820
Deskripsi
| Size (mm) | 4×70 |
|---|---|
| Nominal Cross-Section Area (mm²) | 70 |
| No. of Cores | 4 |
| Nominal Thickness-Insulation (mm) | 1.4 |
| Nominal Thickness-Outer Sheath (mm) | 1.4 |
| Overall Diameter (mm) | 17 |
| Min. Bending Radius (mm) | 210 |
| Standard Delivery Length (m) | 100 |
| Max. Conductor DC (Ω/km) | 0.268 (Resistance at 20°C) |
| Min. Insulation (MΩ/km) | 3 |
| Current Carrying Capacity at 30°C (A) | In Air: 260; In Ground: 240 |
| Short Circuit Current of Conductor (kA) | 8.19 |
| Material | Copper conductor, PVC insulated and PVC sheathed |
