Lenovo IdeaCentre Mini 01IRH8 – i5-13500H / 1x8GB / 512GB SSD / Integrated Intel Iris

PERFORMANCE

• Processor :  Intel® Core™ i5-13500H, 12C (4P + 8E) / 16T, P-core up to 4.7GHz, E-core up to 3.5GHz, 18MB
• Graphics : Integrated Intel® Iris® Xe Graphics Functions as UHD Graphics
• Chipset : Intel® SoC Platform
• Memory : 1x 8GB SO-DIMM DDR4-3200
• Memory Slots : Two DDR4 SO-DIMM slots, dual-channel capable
• Max Memory : Up to 32GB DDR4-3200
• Storage : 512GB SSD M.2 2280 PCIe® 4.0×4 NVMe®
• Optane Memory : None
• Storage Support : Up to two drives, 2x M.2 SSD • M.2 SSD up to 1TB each
• Card Reader : None
• Optical : None
• Audio Chip : High Definition (HD) Audio, Realtek® ALC256 codec
• Speakers :No speakers
• Power Supply : 150W 92%
• Keyboard : None
• Mouse : None
• Expansion Slots : Three M.2 slots (one for WLAN, two for SSD)
• Case Color : Cloud Grey
• System Fan : 2x default
• Stand : Stand
• Form Factor : Tiny (1L)
• Dimensions (WxDxH)  : 191.4 x 195 x 39mm (7.535 x 7.677 x 1.535 inches)
• Weight : Around 1.8 kg (3.97 lbs)

CONNECTIVITY

• Ethernet : 2.5GbE RTL8125BGS
• WLAN + Bluetooth : Wi-Fi® 6, 11ax 2×2 + BT5.1
• Front Ports : 1x USB-C® 3.2 Gen 2
  1x USB 3.2 Gen 2
  1x headphone / microphone combo jack (3.5mm)
• Rear Ports : 1x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer and DP 1.4)
  1x USB 2.0
  1x USB 3.2 Gen 2
  1x HDMI® 2.1 TMDS
  1x DisplayPort™ 1.4
  1x Ethernet (2.5GbE RJ-45)
  1x power connector

SECURITY & PRIVACY

• Security Chip : Firmware TPM 2.0 integrated in processor

MANAGEABILITY

• System Management : None

IdeaCentre_Mini_01IRH8_90W2000UYN
