Prolink 1KVA/900W UPS, Rack-Mount (PRO801ERS)
Rp13.858.350
PROLiNK Professional II Series (1P/1P) is a single-phase UPS system using microprocessor controlled true online double conversion technology and it can be used to provide protection for critical loads especially on IT applications.
GENERAL
| UPS Type | Rack / Tower |
| Phase | Single phase with ground |
| Rating (VA) | 1000 |
| Nominal Power (W) | 900 |
| Standard ModelDimension (mm) | 410 x 438 x 88 [2U] (D x W x H) |
| Weight (kg) | 11.6 |
| Long-run ModelDimension (mm) | 410 x 438 x 88 [2U] (D x W x H) |
| Weight (kg) | 6.4 |
INPUT
| Connection Type | IEC 320-C14 |
| Nominal Voltage | 200/208/220/230/240 VAC |
| Voltage Range | 55-150 VAC ± 5%110-300 VAC ± 5% |
| Frequency Range | 40Hz ~ 70Hz |
| Power Factor | ≧0.99 |
OUTPUT
| Connection Type | 8 x IEC 320-C13 |
| Nominal Voltage | 200/208/220/230/240 VAC |
| Voltage Regulation | ±1% |
| Frequency Range (Synchronized Range) | 47 ~ 53 Hz or 57 ~ 63 Hz |
| Frequency Range (Batt. Mode) | 50 Hz ± 0.5% or 60Hz ± 0.5% |
| Current Crest Ratio | 5:1 (max.) |
| Harmonic Distortion | ≦2% THD (Linear load)≦4% THD (Non-linear load) |
ALARM & INDICATORS
| Battery Mode | Sounding every 4 seconds |
| Low Battery | Sounding every second |
| Overload | Sounding twice every second |
| Fault | Continuously sounding |
| LCD | Load level, Battery Level, AC mode, Battery mode, Bypass mode and Fault |
CONNECTIVITY, CONTROL & MONITORING
| Front panel | Status LED, Function keys, LCD display |
| Communication | Smart RS232*USB Port
Emergency Power Off (EPO) |
BATTERY
| Standard ModelType | 12V / 9Ah |
| Numbers | 2 |
| Typical Recharge Time | 4 hours recover to 90% capacity |
| Long-run ModelType | Depending on the capacity of external batteries |
| Numbers | Depending on the capacity of external batteries |
| Charging Current (max) | 1A / 2A / 4A / 8A |
