RG-S6510-48VS8CQ 25GE Data Center Access Switch
Rp516.992.490
Deskripsi
Spesifikasi
Hardware Specifications
| System Specifications | RG-S6510-48VS8CQ | RG-S6510-32CQ |
| Ports | 48 x 25GE SFP28 ports and 8 × 100GE QSFP28 ports | 32 x 100GE QSFP28 ports |
| Expansion Module Slots | Two power module slots, supporting 1+1 redundancy
Four fan module slots, supporting 3+1 redundancy |
Two power module slots, supporting 1+1 redundancy
Five fan module slots, supporting 4+1 redundancy |
| Management Port | One management port, one console port, and one USB port, compliant with the USB2.0 standard | |
| Switching Capacity | 4.0Tbps | 6.4 Tbps |
| Packet Forwarding Rate | 2000 Mpps | 2030 Mpps |
| 802.1Q VLAN | 4094 | |
| Dimensions and Weight | RG-S6510-48VS8CQ | RG-S6510-32CQ |
| Dimensions
(W × D × H) |
442 mm x 387 mm x 44 mm (17.40 in. x 15.24 in. x 1.73 in., 1 RU) | 442 mm x 560 mm x 44 mm (17.40 in. x 22.05 in. x 1.73 in., 1 RU) |
| Weight | About 8.2 kg (18.08 lbs, including two power supply modules and four fan modules) | About 11.43 kg (25.20 lbs, including two power supply modules and five fan modules) |
| Power Supply and Consumption | RG-S6510-48VS8CQ | RG-S6510-32CQ |
| AC | ● Rated voltage: 110 V AC/220 V AC
● Rated voltage range: 100 V AC to 240 V AC (50 Hz to 60 Hz) ● Max voltage range: 90 V AC to 264 V AC (47 Hz to 63 Hz) ● Rated input current range: 3.5 A to 7.2 A |
|
| High-voltage DC | Input voltage range: 192 V DC to 288 V DC
Input current: 3.6 A |
|
| Low-voltage DC | ● Input voltage range: –36 V DC to –72 V DC
● Rated input voltage: –48 V DC ● Rated input current: 23 A |
N/A |
| Maximum Power Consumption | ● Max: 300 W
● Typical: 172 W ● Static: 98 W |
● Max: 450 W
● Typical: 270 W ● Static: 150 W |
| Environment and Reliability | RG-S6510-48VS8CQ | RG-S6510-32CQ |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) | 0°C to 40°C (32ºF to 104ºF) |
| Storage temperature | -40 °C to 70 °C (-40 °F to 158 °F) | |
| Operating Humidity | 10%RH to 90% RH (Non-condensing) | |
| Storage humidity | 5% to 95% RH (non-condensing) | |
| Working altitude | Operating altitude: up to 5000 m (16,404.20 ft.) Storage altitude: up to 5000 m (16,404.20 ft.) |
|
Software Specifications
| Software Specifications | RG-S6510-48VS8CQ | RG-S6510-32CQ |
| L2 Protocols | IEEE802.3ad (Link Aggregation Control Protocol), IEEE802.1p, IEEE802.1Q, IEEE802.1D (STP), IEEE802.1w (RSTP), IEEE802.1s (MSTP), IGMP Snooping, MLD Snooping, Jumbo Frame (9 KB), IEEE802.1ad (QinQ and Selective QinQ), GVRP | |
| L3 Protocols (IPv4) | BGP4, OSPFv2, RIPv1, RIPv2, MBGP, LPM Routing, Policy-based Routing (PBR), Route-policy, Equal-Cost Multi-Path Routing (ECMP), WCMP, VRRP, IGMP v1/v2/v3, DVMRP, PIM-SSM/SM/DM, MSDP, Any-RP | |
| IPv6 Basic Protocols | Neighbor Discovery, ICMPv6, Path MTU Discovery, DNSv6, DHCPv6, ICMPv6, ICMPv6 redirection, ACLv6, TCP/UDP for IPv6, SNMP v6, Ping/Traceroute v6, IPv6 RADIUS, Telnet/SSH v6, FTP/TFTP v6, NTP v6, IPv6 MIB support for SNMP, VRRP for IPv6, IPv6 QoS | |
| IPv6 Features | Static routing, ECMP, PBR, OSPFv3, RIPng, BGP4+, MLDv1/v2, PIM-SMv6, manual tunnel, automatic tunnel, IPv4 over IPv6 tunnel, and ISATAP tunnel | |
| Multicast | IGMPv1, v2, v3、IGMP Host Behavior、Member Query and Response、Querier Election、IGMP Proxy、Multicast Static Routing、MSDP、PIM-DM、PIM-SM、PIM-SSM、Enabling PIM on Layer-3 Subinterface、PIM-SMv6、MLD v1 and v2、MLD Proxy、Enabling PIMv6 on Layer-3 Subinterface | |
| ACL | Standard IP-based ACL、Extended MAC/IP-based ACL、Expert-level ACL、ACL 80、IPv6 ACL、ACL Logging、ACL Counter (Ingress and egress counters are supported in interface or global configuration modes)、ACL Re-marking、Global ACL、ACL-based Redirection、Displaying ACL Resources、Processing First Packet of TCP Handshake When Binding the ACL to Restrict SIP、Matching Against 5-Tuple of Pass-by VXLAN Inner IP Packets、The expert-level ACL supports matching the IP flag and DSCP fields of VXLAN inner packets、Ingress/Egress ACLs | |
| When the same ACL is applied to different physical interfaces or SVIs, resources can be multiplexed | N/A | |
| Data Center Features | VXLAN routing and VXLAN bridging
IPv6 VXLAN over IPv4 and EVPN VXLAN PFC, ECN, and RDMA M-LAG *RoCE over VxLAN OpenFlow 1.3 |
|
| Visualization | gRPC
sFLOW sampling INT |
|
| QoS | Mapping of IEEE 802.1p, DSCP, and ToS priorities ACL-based traffic classification Priority marking/remarking Multiple queue scheduling mechanisms, including SP, WRR, DRR, SP+WRR, and SP+DRR Congestion avoidance mechanisms such as WRED and tail discarding |
|
| Virtualization | Virtual Switching Unit | |
| Buffer Management | Buffer status monitoring and management, and identification of burst traffic | |
| HA Design | GR for RIP/OSPF/BGP, BFD, DLDP, REUP dual-link fast switching, RLDP unidirectional link detection, 1+1 power redundancy and fan redundancy, and hot swapping for all cards and power supply modules | |
| Security Features | Network Foundation Protection Policy (NFPP), CPP, DDoS attack defense, illegitimate data packet detection, data encryption, source IP spoofing prevention, IP scanning prevention, RADIUS/TACACS, IPv4/v6 packet filtering by basic ACL, extended ACL or VLAN-based ACL, plaintext-based and MD5 ciphertext-based authentication for OSPF, RIPv2, and BGPv4 packets, telnet login and password mechanisms for restricted IP addresses, uRPF, broadcast packet suppression, DHCP Snooping, ARP spoofing prevention, ARP check, and hierarchical user management | |
| Management Mode | SNMP v1/v2c/v3, Netconf, telnet, console, MGMT, RMON, SSHv1/v2, FTP/TFTP, NTP clock, Syslog, SPAN/RSPAN/ERSPAN, Telemetry, ZTP, Python, fan and power alarm, and temperature alarm | |
| Other Protocols | DHCP Client, DHCP Relay, DHCP Server, DNS Client, UDP relay, ARP Proxy, and Syslog | |
