Spesifikasi singkat:
| Used with UPS Model | GXT5 750VA and 1000 VA |
| Rated Voltage | 36 V |
| Charger Current | Nominal 2.2 A; Maximum 8 A |
| Type | Valve-regulated, non-spillable, lead acid |
| Qty x V x Rating | 3 x 12 V x 9.0 Ah |
| End Cell Voltage | 1.67 V/cell (discharge voltage per cell will be from 1.67 Vdc to 1.90 Vdc, canbe selected by PARAMSET) |
| Floating Voltage | Equalize charge: 2.35 V/cell; Float charge: 2.27 V/cell |
| Battery Voltage Range | 30 Vdc to 42.3 Vdc |
