Fortinet FORTIAP U323EV

• Hardware Type : Indoor AP
• Number of Radios : 2 + 1 BLE
• Number of Antennas : 6 External (RP-SMA) + 1 BLE Internal
• Antenna Type and Peak Gain : Dipole: 3.5 dBi for 2.4 GHz, 5 dBi for 5 GHz
• Frequency Bands (GHz) : 2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725,
  5.725–5.850
• Radio 1 Capabilities : 2.4 GHz b/g/n (3×3:3 stream) 20/40 MHz (64 QAM)
• Radio 2 Capabilities : 5 GHz a/n/ac (3×3:3 stream) 20/40/80 MHz (256 QAM)
• Maximum Data Rate : Radio 1: up to 450 Mbps
  Radio 2: up to 1,733 Mbps
• Bluetooth Low Energy Radio : Bluetooth scanning and iBeacon advertisement @ 4 dBm
  max TX power
• Interfaces : 2x 10/100/1000 Base-T RJ45, 1x Type A USB,
  1x RS-232 RJ45 Serial Por
• Power over Ethernet (PoE) : Dual redundant PoE power ports with support for IEEE
  802.3at (20 dBm TX Power and USB disabled with 802.3af)
• Simultaneous SSIDs : Up to 16 (14 if background scanning enabled)
• EAP Type(s) : EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0/EAP-MSCHAPv2,
  PEAPv1/EAP-GTC EAP-SIM, EAP-AKA, EAP-FAST
• User/Device Authentication : WPA™, WPA2™, and WPA3™ with 802.1x or Preshared key,
  WEP, Web Captive Portal, MAC blocklist and allowlist
• Maximum Tx Power (Conducted) : 2.4 GHz: 26.7 dBm / 468 mW (3 chains combined)*
  5 GHz: 24.7 dBm / 295 mW (3 chains combined)*
• Kensington Lock : Yes
• IEEE Standards : 802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i,
  802.11j, 802.11k, 802.11n, 802.11v, 802.11w, 802.11ac, 802.1Q, 802.1X, 802.3af, 802.3at, 802.3az, 802.3ad
• SSID Types Supported : Local-Bridge, Tunnel & Mesh
• Per Radio Client Capacity : Up to 256
• Cellular Co-existence** : Yes
• Reset Button : Yes
• LED Off Mode : Yes

DataSheet FORTIAP U323EV

DataSheet FORTIAP U323EV.pdf
